IPC 2226A

Description

IPC 2226A – Sectional Design Standard for High Density Interconnect (HDI) Printed Boards

IPC-2226A, Sectional Design Standards for High Density Interconnect (HDI) Printed Boards is used in conjunction with IPC-2221B. The IPC-2226A standard establishes requirements and considerations for the design of high density interconnect (HDI) printed boards and microvia technology. Revision A constitutes a substantial update to the document, with an all new color key for HDI constructions, new coverage of routing density factors and a complete rebuild of feature size recommendations, including aspect ratio, capture and target land sizes. Almost every graphic in Sections 3, 5 and 9 has been revised and/or supplemented with new graphics addressing various microvia formation processes and HDI constructions.

Product Details

Published:

09/01/2017

ISBN(s):

9781611933246, 9781951577025

Number of Pages:

48

File Size:

1 file , 2.8 MB

Product Code(s):

2226-STD-0-P-0-EN-A, 2226-STD-0-D-0-JP-A, 2226-STD-0-P-0-EN-A

Note:

This product is unavailable in Russia, Ukraine, Belarus
